Our products offer a variety of designs and features to address a wide range of end-user applications.
These blocks are made of Bakelite for excellent temperature performance for a plastic block. Pass through holes in the ceramic base allow leads to mount directly into the bottom of each terminal.
| PART SPECIFICATIONS | CARTON SPECIFICATIONS | |||||
|---|---|---|---|---|---|---|
| Part # | Number of Terminals | Material | Terminal Style | Full Qty. | Dimensions (inches) | Wt. (lbs.) |
| 902 | 2 | Bakelite | Ni Pl. Brass | 50 | 12x12x2.25 | 4 |
| 903 | 3 | Bakelite | Ni Pl. Brass | 50 | 12x12x2.25 | 5 |
| 904 | 4 | Bakelite | Ni Pl. Brass | 50 | 12x12x2.25 | 6 |
